- Power 230Vac.
- Force 15Nm.
- Locking.
- With encoder.
- IP44 Protection class.
- No external limit switches.
- LED programming.
- Built-in control board in the motor.
- Self-learning of open/close distances.
- Direct current motor.
- Innovative pinion system adaptable to rack variations.
- Maximum door weight 400 kg in optimal conditions.
- There is the option of batteries housed in the control board (two 1.2 Ah batteries each, ADN01 code, not included in the kit).
Dingo
24Vdc residential up-and-over pinion electromechanical motor for sliding doors up to 400kg.
Advantages:
- Obstacle detection to ensure safety.
- Ultraquiet operation.
- Practical key unlocking system.
- Attractive design.
- High protection from water and dirt.
- Can be used in all temperatures between -20/+6.
Product datasheet
Technical manual
DINGO Motor for Residential Sliding Doors
24Vdc DINGO up-and-over pinion motor for residential sliding doors up to 400kg with the option of battery operation.
