Toro

Category Sliding Gate Motor

230Vac single-phase and 400Vac three-phase electromechanical motor for community and industrial sliding doors up to 2500kg.

Advantages:

Practical unlocking system with personalised key.
Very high usage factor.
Oil-cooled gearbox.
High protection from water and dirt.
Can be used in all temperatures between -20/+55.
Motor with reference KM2500 has greater power.
Obstacle detection to ensure safety.
Low noise level.

Description
Downloads

TORO electromechanical motor for community and industrial sliding doors

230Vac single-phase TO1810EC TORO motor for high-use sliding, community and industrial doors up to 1200-1800kg with magnetic limit switches.

400Vac KM2500 three-phase TORO motor for high-use sliding, community and industrial doors up to 2500kg with magnetic limit switches.

Technical characteristics

Power 230Vac.
Force 45-70Nm.
Locking.
Very high usage factor.
Maximum door weight 1200-1800/2500kg.
IP55 Protection class.
Magnetic limit switches.
Mechanical torque adjustment.
Oil-cooled gearbox.
KM1800 control board built into the motor.

Product datasheet

Technical manual

Other downloads

Spare parts list TORO
